Description
Standard 3rd G Multihead Weigher is suitable for weighing seeds, nuts, almonds, peanuts, raisins, pistachio, potato chips, candy, dumplings and other granule, sheet, strip, round shape material.
Features:
1.Special load cell with high precision and high standard;
2.Intelligent fault alarm, convenient maintenance;
3.High speed staggered discharging function, effectively prevent blocking materials;
4.With high integrated modular design makes mechanical and electronic components easy to install and maintenance;
5.Modbus industry standard communication protocol, realize the interface combination of multihead weigher and packaging machine;
Model | A10 | A14 |
Identify Code | A10-3-2 | A14-3-2 |
Weighing Range | 10-1000g | 10-1500g |
Accuracy | X(0.5) | X(0.5) |
Max Speed | 65P/M | 120P/M |
Hopper Volume | 1.6L/2.0L | |
Control Panel | 9.7" Touch Screen | |
Options | Dimple Plate/Timing Hopper/Printer/Overweight Reject Device | |
Driving System | Step Motor | |
Power Requirement | 220V/1000W/ 50/60Hz /10A | 220V/1500W/ 50/60Hz /10A |
Packing Dimension(mm) | 1620(L)*1080(W)*1100(H) | 1760(L)X1190(W)X1390(H) |
Gross Weight | 400kg | 500kg |
